Smooth Shank Self Adhesive Insulation Hangers Perforated Steel Welding Insulation Pins 44 holes

Smooth Shank Self Adhesive Insulation Hangers Perforated Steel Welding Insulation Pins 44 holes

MOQ: 5000pcs
Price: $0.098-0.35/piece
Payment Terms: T/T, D/A, D/P, L/C, Western Union
Supply Ability: 5 million sets
Detail Information
Place of Origin:
Hebei, China
Certification:
ISO9001
Type:
Self Stick Up Pins
Material:
Steel
Base Size:
25*25mm, 35*35mm, 50*50mm
Insulation Features:
Fire Resistant, Soundproofing Insulation, Water Resistant
Name:
Self Adhesive Insulation Pin
Point:
Sharp Point
Finish:
Zinc Plated
Application:
Marine Engine Rooms
Packaging Details:
Cartons+plastic Bags+pallet
Highlight:

steel welding insulation pins

,

smooth shank self adhesive insulation hangers

,

welding insulation pins 44 holes

Product Description

Adhesive Insulation Hanger Pins with Smooth Shank Perforated Steel Insulation Welding Pins






Product Description



Aluminum insulation nails, also known as self-adhesive insulation nails, have the advantages of being convenient for workers to construct, easy to bond, and time-saving. The thickness of galvanized sheet is between 0.5MM-0.6MM. The common specification abroad is that the side length of the bottom plate is the same as the length of the nails. Generally, if the side length of the bottom plate is 3.8CM, the nails will be made 3.8CM long and can be made of stainless steel or aluminum wire.











Product Features



Strong corrosion resistance: The galvanizing process effectively prevents seawater corrosion and is suitable for long-term fixation of ship metal structures and insulation layers. ‌
High bearing capacity: The nail body is made of high-quality steel and can withstand ship vibration and pressure changes. ‌

Easy installation: No need for complex tools, installation can be completed by hammering or welding. ‌

Flame retardant properties: Some products meet the flame retardant standards and comply with ship fire prevention requirements.







technical Parameters



Base
Material
Galvanized steel / Stainless steel
Dimensions
50 x 50 mm (2” x 2”) ,25X25mm(1”X1”)
Perforation
44 holes, dia. 3.0 mm
Shank
Material
Mild steel(Galvanized or copper coating)
Stainless steel ,Aluminum
Lengths
32 to 270 mm (1-1/4” to 10-5/8”)
Locking washer
Material
Galvanized spring steel/ Stainless steel
Diameter
Round : 30mm , Square:1-1/8 X 1-1/4””
Edges
Bevelled
